| 1 |
Circuit 15, status |
12J |
| 2 |
Circuit 61, status |
8K |
| 2 |
Circuit 61, status |
10J |
| 3 |
Vehicle speed, signal |
16J |
| 4 |
Circuit 58d, status |
16H |
| 5 |
Power window motor, signal |
19H |
| 5 |
Power window motor, signal |
21H |
| 6 |
Tilting/sliding roof motor, signal |
25H |
| 7 |
Panoramic sliding sunroof motor, signal |
27H |
| 8 |
Outside temperature, signal |
8H |
| 8 |
Outside temperature, signal |
10H |
| 9 |
Refrigerant pressure, signal |
8J |
| 9 |
Refrigerant pressure, signal |
10H |
| 10 |
Rear automatic air conditioning operating unit, request |
15E |
| 11 |
NOT FOUND |
15D |
| 12 |
Pollutant sensor, signal |
15C |
| 13 |
Evaporator temperature sensor, signal |
17C |
| 14 |
Interior temperature sensor, signal |
18C |
| 14 |
Interior temperature sensor, signal |
19E |
| 14 |
Interior temperature sensor, signal |
25G |
| 15 |
Sun sensor, signal |
19D |
| 16 |
Air outlet temperature sensor, signal |
19E |
| A1 |
Instrument cluster |
15J |
| A8/1 |
Transmitter key |
13L |
| A98 |
Panoramic sliding roof control module |
27J |
| B10/31 |
Left side air outlet temperature sensor |
25E |
| B10/32 |
Right side air outlet temperature sensor |
25E |
| B10/35 |
Left front footwell air outlet temperature sensor |
25F |
| B10/36 |
Right front footwell air outlet temperature sensor |
25F |
| B10/38 |
Rear footwell air outlet temperature sensor |
25G |
| B10/4 |
Interior temperature sensor |
21A |
| B10/6 |
Evaporator temperature sensor |
17B |
| B11/12 |
Dew point sensor |
11C |
| B12 |
Refrigerant pressure sensor |
6H |
| B14 |
Outside temperature sensor |
7G |
| B31 |
Emissions sensor |
11B |
| B32/3 |
Sun sensor |
23A |
| CAN B |
Interior CAN |
11G |
| CAN B |
Interior CAN |
19G |
| CAN E |
Chassis CAN |
5K |
| Code 413 |
Panoramic sliding sunroof |
26J |
| Code 414 |
Electric glass tilting/sliding roof |
23J |
| Code 581 |
Comfort automatic air conditioning |
9A |
| Code 581 |
Comfort automatic air conditioning |
24F |
| LIN B8 |
Climate control LIN |
13E |
| LIN B8 |
Climate control LIN |
13D |
| LIN B8 |
Climate control LIN |
13C |
| N10/1 |
Front SAM control unit with fuse and relay module |
8J |
| N22/4 |
Rear automatic air conditioning operating unit |
10E |
| N22/7 |
Automatic air conditioning control and operating unit |
17D |
| N3/10 |
ME-SFI [ME] control unit |
5E |
| N3/9 |
CDI control unit |
2 E |
| N69/1 |
Left front door control unit |
18H |
| N69/2 |
Right front door control unit |
18J |
| N69/3 |
Left rear door control unit |
21H |
| N69/4 |
Right rear door control unit |
21J |
| N70 |
Overhead control panel control unit |
24J |
| N70/3 |
Overhead control panel electronics |
25B |
| N70/3b1 |
Interior temperature sensor with integrated fan |
25B |
| N70b1 |
Interior temperature sensor with integrated fan |
25J |
| N73 |
Electronic ignition switch control unit |
11J |
| U111 |
Valid for overhead control panel without CAN |
24A |
| U113 |
Valid for 2-zone THERMATIC |
16D |
| U114 |
Valid for 3-zone THERMOTRONIC |
16D |
| U74 |
Valid for diesel engines |
1E |
| U75 |
Valid for gasoline engines |
4E |
