| A0 |
Explanation of color code |
40 L |
| A2/49a1 |
CTEL antenna |
7L |
| A2/49a1x1 |
Telephone antenna connector |
7J |
| A2/53 |
Phone/CTEL/STH radio remote control antenna splitter |
11 L |
| A2/91 |
Bluetooth antenna |
38 L |
| A28/2 |
Portable CTEL antenna amplifier |
14L |
| A28/2 |
Portable CTEL antenna amplifier |
18L |
| A28/3 |
E-net compensator |
14L |
| A28/3 |
E-net compensator |
18L |
| A34/13 |
Rear portable CTEL bracket |
6L |
| A34/15 |
UHI portable CTEL holder (Universal Handy Interface) |
22 L |
| A34/15x1 |
Connector 1, UPCI [UHI] portable CTEL holder (Universal Interface) Handy |
21 J |
| A34/15x2 |
Connector 2, UPCI [UHI] portable CTEL holder (Universal Interface) Handy |
19J |
| A67b1 |
Hands-free system microphone group |
29 L |
| A67b1 |
Hands-free system microphone group |
33 L |
| A67b1x1 |
Hands-free system microphone group connector |
27 H |
| A67b1x1 |
Hands-free system microphone group connector |
31 H |
| N10/2 |
Rear SAM control module with fuse and relay module |
2L |
| N123/1 |
Universal Portable CTEL Interface (UPCI [UHI]) control module |
4A |
| N123/1 |
Universal Portable CTEL Interface (UPCI [UHI]) control module |
12A |
| N123/1 |
Universal Portable CTEL Interface (UPCI [UHI]) control module |
20 A |
| N123/1 |
Universal Portable CTEL Interface (UPCI [UHI]) control module |
28 A |
| N123/1 |
Universal Portable CTEL Interface (UPCI [UHI]) control module |
36 A |
| U1 |
Valid for {{USA}} |
13F |
| U20 |
Valid for all except {{USA}}{{Japan}} |
13F |
| U402 |
Valid for rear telephone |
5E |
| U434 |
Not valid for VCS [SBS] |
27 C |
| U434 |
Not valid for VCS [SBS] |
31 C |
| U579 |
Valid for stationary heater (STH) |
10F |
| W6 |
Ground (left wheelhousing in trunk) |
16D |
| X25/8 |
Overhead control panel and FFS [RBA] connector |
27 E |
| X25/8 |
Overhead control panel and FFS [RBA] connector |
32 E |
| X39/37 |
CTEL separation point |
22 E |
| X39/39 |
Handy connector |
17H |
| X39/39 |
Handy connector |
19H |
| X39/48 |
Breakdown assistance/info button connector |
20 H |
| X39/57 |
Bluetooth module connector |
5H |
| Z20/30 |
Tracer wire connector sleeve |
22 H |
| Z6/56 |
Circuit 31 connector sleeve |
5E |
| Z6/56 |
Circuit 31 connector sleeve |
15E |
| Z7/40 |
Circuit 30 connector sleeve |
2E |
