| 1 |
Circuit 15, status |
14E |
| 10 |
Hazard warning system button indicator lamp, actuation |
5K |
| 2 |
Combination switch, status |
21G |
| 2 |
Combination switch, status |
19K |
| 2 |
Combination switch, status |
17E |
| 3 |
Hazard warning flasher button, status |
15G |
| 3 |
Hazard warning flasher button, status |
17F |
| 4 |
Crash, signal |
23F |
| 4 |
Crash, signal |
18E |
| 5 |
Central locking (CL[ZV]), status |
14E |
| 6 |
Taxi alarm, signal |
17H |
| 7 |
Flasher frequency, signal |
8J |
| 7 |
Flasher frequency, signal |
16D |
| 7 |
Flasher frequency, signal |
3F |
| 7 |
Flasher frequency, signal |
24H |
| 7 |
Flasher frequency, signal |
12H |
| 7 |
Flasher frequency, signal |
20E |
| 8 |
Turn signal lamp, actuation |
19C |
| 8 |
Turn signal lamp, actuation |
26C |
| 8 |
Turn signal lamp, actuation |
10K |
| 8 |
Turn signal lamp, actuation |
25C |
| 8 |
Turn signal lamp, actuation |
25B |
| 8 |
Turn signal lamp, actuation |
20C |
| 8 |
Turn signal lamp, actuation |
20B |
| 8 |
Turn signal lamp, actuation |
2C |
| 8 |
Turn signal lamp, actuation |
13C |
| 8 |
Turn signal lamp, actuation |
8C |
| 9 |
Hazard warning flasher, status |
8J |
| A1 |
Instrument cluster |
24J |
| A1e1 |
Left turn signal indicator lamp |
23J |
| A1e2 |
Right turn signal indicator lamp |
23J |
| A1h2 |
Audible turn signal indicator |
23K |
| A40/9 |
Front central operating unit |
2J |
| A40/9s3 |
Hazard warning system button |
4K |
| A8/1 |
Transmitter key |
6B |
| CAN B |
Interior CAN |
16D |
| CAN B |
Interior CAN |
12G |
| CAN B |
Interior CAN |
12F |
| CAN B |
Interior CAN |
12F |
| CAN B |
Interior CAN |
6F |
| CAN B |
Interior CAN |
6F |
| CAN B |
Interior CAN |
16J |
| CAN B |
Interior CAN |
14H |
| CAN E |
Chassis CAN |
22H |
| CAN E |
Chassis CAN |
24F |
| CAN F |
Central CAN |
23H |
| Code 550 |
Trailer hitch |
9G |
| Code 934 |
Taxi emergency alarm system |
15K |
| E1e5 |
Left turn signal lamp |
25D |
| E1n6 |
Left turn signal and cornering light voltage converter |
25C |
| E2e5 |
Right turn signal lamp |
20D |
| E2n6 |
Right turn signal and cornering light voltage converter |
20C |
| E3e1 |
Left turn signal lamp |
8C |
| E4e1 |
Right turn signal lamp |
13C |
| E6/5 |
Left outside mirror turn signal lamp |
2B |
| E6/6 |
Right outside mirror turn signal lamp |
2B |
| N10/1 |
Front SAM control unit with fuse and relay module |
16A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
16E |
| N2/7 |
Restraint systems control unit |
27E |
| N26/9 |
Special vehicle multifunction control unit (SVMCU [MSS]) |
16K |
| N28/1 |
Trailer recognition control unit |
11H |
| N69/1 |
Left front door control unit |
2E |
| N69/2 |
Right front door control unit |
2E |
| N72/1 |
Upper control panel control unit |
7K |
| N73 |
EIS [EZS] control unit |
5B |
| N80 |
Steering column module |
21J |
| N93 |
Central gateway control unit |
22E |
| S4s1 |
Left and right turn signal switch |
19J |
| U254 |
Valid for LED lamp unit |
25C |
| U254 |
Valid for LED lamp unit |
20C |
| X58 |
Trailer hitch socket (13-pin) |
11K |
