| A17/3 |
Left rear KEYLESS GO door handle |
22 L |
| A17/3x1 |
Left rear KEYLESS-GO door handle connector |
22 K |
| A17/4 |
Right rear KEYLESS GO door handle |
59 L |
| A17/4x1 |
Right rear KEYLESS-GO door handle connector |
59 K |
| A2/39 |
Left rear door KEYLESS-GO antenna |
23 L |
| A2/41 |
Right rear door KEYLESS-GO antenna |
60 L |
| A40/3 |
COMAND operating, display and control unit |
31 A |
| A40/3 |
COMAND operating, display and control unit |
69 A |
| B48/10 |
Rear door pressure sensor, passenger-side |
53 L |
| B48/9 |
Rear door pressure sensor, driver-side |
15 L |
| E17/13 |
Left rear inside door handle illumination |
13 L |
| E17/14 |
Right rear door inside handle illumination |
51 L |
| E17/5 |
Left rear door entrance/exit lamp |
12 L |
| E17/6 |
Right rear door entrance/exit lamp |
49 L |
| H4/3 |
Left rear door speaker |
26 L |
| H4/33 |
Left front door tweeter |
32 L |
| H4/34 |
Right front door tweeter |
70 L |
| H4/35 |
Left rear door tweeter |
27 L |
| H4/36 |
Right rear door tweeter |
65 L |
| H4/4 |
Right rear door speaker |
63 L |
| H4/5 |
Left front door speaker |
31 L |
| H4/6 |
Right front door speaker |
68 L |
| M10/5 |
Left rear power window motor |
4 L |
| M10/6 |
Right rear power window motor |
35 L |
| M14/8 |
Left rear door CL [ZV] motor |
1 L |
| M14/8 |
Left rear door CL [ZV] motor |
10 L |
| M14/8 |
Left rear door CL [ZV] motor |
19 L |
| M14/9 |
Right rear door CL [ZV] motor |
47 L |
| M14/9 |
Right rear door CL [ZV] motor |
56 L |
| N10 |
Front SAM control unit |
4 A |
| N10 |
Front SAM control unit |
36 A |
| N10/8 |
Rear SAM control unit |
12 A |
| N10/8 |
Rear SAM control unit |
48 A |
| N2/7 |
Restraint systems control unit |
16 A |
| N2/7 |
Restraint systems control unit |
54 A |
| N40/3 |
Amplifier for sound system |
26 A |
| N40/3 |
Amplifier for sound system |
63 A |
| N69/5 |
KEYLESS-GO control unit |
19 A |
| N69/5 |
KEYLESS-GO control unit |
59 A |
| S21/3 |
Left rear power window switch |
7 L |
| S21/4 |
Right rear power window switch |
39 L |
| U500 |
Not valid for Sound System |
28 A |
| U500 |
Not valid for Sound System |
28 A |
| U500 |
Not valid for Sound System |
66 A |
| U500 |
Not valid for Sound System |
66 A |
| U596 |
Valid for rear sidebag |
14 C |
| U596 |
Valid for rear sidebag |
52 C |
| U656 |
Valid for interior light package |
13 C |
| U656 |
Valid for interior light package |
50 C |
| U82 |
Valid for KEYLESS GO |
20 A |
| U82 |
Valid for KEYLESS GO |
20 A |
| U82 |
Valid for KEYLESS GO |
57 A |
| U82 |
Valid for KEYLESS GO |
57 A |
| W17 |
Ground (right rear seat) |
43 A |
| X35/3 |
Left rear door separation point |
1 E |
| X35/4 |
Right rear door separation point |
34 E |
| X8/16 |
Left rear door printed wiring harness connector |
5 H |
| X8/16 |
Left rear door printed wiring harness connector |
11 H |
| X8/17 |
Right rear door printed wiring harness connector |
37 H |
| X8/17 |
Right rear door printed wiring harness connector |
48 H |
| X8/36 |
Left rear door handle connector |
22 H |
| X8/37 |
Right rear door handle connector |
59 H |
| Z204 |
Wake-up signal/circuit 58d voltage distributor connector |
8 A |
| Z204 |
Wake-up signal/circuit 58d voltage distributor connector |
41 A |
| Z204/3 |
Circuit 31 right rear seat voltage distributor connector |
44 A |
| Z204/9 |
Circuit 31 left rear seat voltage distributor connector (3) |
9 A |
| Z51/6 |
Circuit 58d interior connector sleeve |
8 A |
| Z51/6 |
Circuit 58d interior connector sleeve |
41 A |
| Z6/12 |
Left rear door ground connector sleeve |
9 G |
| Z6/13 |
Right rear door ground connector sleeve |
42 G |
