| 1 |
Circuit 15, status |
13 C |
| 2 |
Combination switch, status |
14 D |
| 2 |
Combination switch, status |
19 C |
| 2 |
Combination switch, status |
21 B |
| 3 |
Hazard warning flasher switch, status |
11 D |
| 4 |
Emergency stop, signal |
15 D |
| 4 |
Emergency stop, signal |
19 D |
| 5 |
Crash, signal |
15 D |
| 5 |
Crash, signal |
19 C |
| 6 |
Central locking (CL[ZV]), status |
13 C |
| 7 |
Flasher frequency, signal |
4 F |
| 7 |
Flasher frequency, signal |
5 C |
| 7 |
Flasher frequency, signal |
5 H |
| 7 |
Flasher frequency, signal |
11 H |
| 7 |
Flasher frequency, signal |
16 F |
| 8 |
Turn signal lamp, actuation |
3 J |
| 8 |
Turn signal lamp, actuation |
9 J |
| 8 |
Turn signal lamp, actuation |
15 J |
| 8 |
Turn signal lamp, actuation |
20 J |
| 8 |
Turn signal lamp, actuation |
21 J |
| 8 |
Turn signal lamp, actuation |
26 J |
| A1 |
Instrument cluster |
2 F |
| A1e1 |
Left turn signal indicator lamp |
1 E |
| A1e2 |
Right turn signal indicator lamp |
3 E |
| A1h2 |
Audible turn signal indicator |
2 E |
| A8/1 |
Transmitter key |
10 B |
| CAN B |
Interior CAN |
7 F |
| CAN B |
Interior CAN |
7 E |
| CAN B |
Interior CAN |
7 E |
| CAN B |
Interior CAN |
10 H |
| CAN B |
Interior CAN |
11 B |
| CAN B |
Interior CAN |
14 G |
| CAN B |
Interior CAN |
15 D |
| CAN C |
Engine compartment CAN |
18 C |
| CAN C |
Engine compartment CAN |
20 C |
| CAN C |
Engine compartment CAN |
22 D |
| E1e5 |
Left turn signal lamp |
19 K |
| E2e5 |
Right turn signal lamp |
15 K |
| E3e1 |
Left turn signal lamp |
21 K |
| E4e1 |
Right turn signal lamp |
25 K |
| E6/5 |
Left outside mirror turn signal lamp |
8 J |
| E6/6 |
Right outside mirror turn signal lamp |
2 J |
| N10 |
Front SAM control unit |
17 F |
| N10/8 |
Rear SAM control unit |
12 D |
| N2/7 |
Restraint systems control unit |
18 A |
| N47-5 |
ESP control unit |
24 A |
| N69/1 |
Left front door control unit |
10 J |
| N69/2 |
Right front door control unit |
5 J |
| N72/1 |
Upper control panel control unit |
4 B |
| N72/1s5 |
Hazard warning system switch |
4 A |
| N73 |
EIS [EZS] control unit |
9 A |
| N80 |
Steering column module |
22 A |
| N93 |
Central gateway control unit |
18 D |
| S4 |
Combination switch |
20 A |
