| A9/1 |
AIRMATIC compressor unit |
17 L |
| A9/1m1 |
Air compressor motor |
17 L |
| A9/1y1 |
AIRMATIC pressure reduction valve |
16 L |
| B22/10 |
Right rear level sensor |
52 L |
| B22/7 |
Left rear level sensor |
53 L |
| B22/8 |
Left front level sensor |
45 L |
| B22/9 |
Right front level sensor |
38 L |
| B24/3 |
Left front body lateral acceleration sensor |
46 L |
| B24/4 |
Right front body lateral acceleration sensor |
14 L |
| B24/6 |
Right rear body lateral acceleration sensor |
56 L |
| B24/6 |
Right rear body lateral acceleration sensor |
59 L |
| F4 |
Load compartment fuse and relay box |
5 L |
| F4f32 |
Fuse 32 |
2 L |
| F4f53 |
Fuse 53 |
3 L |
| F58 |
Engine compartment fuse and relay box |
20 L |
| F58f108 |
Fuse 108 |
19 L |
| N10 |
Front SAM control unit |
9 L |
| N51 |
AIRMATIC with ADS control unit |
4 A |
| N51 |
AIRMATIC with ADS control unit |
13 A |
| N51 |
AIRMATIC with ADS control unit |
20 A |
| N51 |
AIRMATIC with ADS control unit |
28 A |
| N51 |
AIRMATIC with ADS control unit |
36 A |
| N51 |
AIRMATIC with ADS control unit |
44 A |
| N51 |
AIRMATIC with ADS control unit |
51 A |
| N51 |
AIRMATIC with ADS control unit |
59 A |
| N51 |
AIRMATIC with ADS control unit |
67 A |
| U151 |
Valid for engine 113 |
40 C |
| U152 |
Valid for engine 156 |
57 G |
| U506 |
Valid for ADS |
55 A |
| U681 |
Valid for all except M113 |
47 C |
| W15/1 |
Ground (right footwell) |
6 E |
| W2 |
Ground (right front, at lamp unit) |
17 F |
| X25/2 |
Engine compartment/interior compartment connector |
11 E |
| X25/2 |
Engine compartment/interior compartment connector |
41 E |
| X25/2 |
Engine compartment/interior compartment connector |
43 E |
| X25/2 |
Engine compartment/interior compartment connector |
47 E |
| X30/19 |
Passenger-side voltage distributor (CAN C) connector |
67 L |
| Y36 |
AIRmatic valve unit |
33 L |
| Y36 |
AIRmatic valve unit |
37 L |
| Y36b1 |
AIRMATIC pressure sensor |
36 L |
| Y36y1 |
Left front level control valve |
32 K |
| Y36y2 |
Right front level control valve |
32 J |
| Y36y3 |
Left rear level control valve |
32 J |
| Y36y4 |
Right rear level valve |
32 H |
| Y36y5 |
AIRMATIC central reservoir charge valve |
32 K |
| Y51 |
Left front axle damping valve unit |
49 L |
| Y51x1 |
Left front axle damping valve unit connector |
48 J |
| Y51y1 |
Solenoid valve 1, front left |
48 L |
| Y51y2 |
Solenoid valve 2, front left |
49 L |
| Y52 |
Right front axle damping valve unit |
13 L |
| Y52x1 |
Right front axle damping valve unit connector |
11 J |
| Y52y1 |
Solenoid valve 1, front right |
12 L |
| Y52y2 |
Solenoid valve 2, front right |
13 L |
| Y53 |
Left rear axle damping valve unit |
61 L |
| Y53x1 |
Damping valve unit connector |
60 J |
| Y53y1 |
Solenoid valve 1, rear left |
61 L |
| Y53y2 |
Solenoid valve 2, rear left |
62 L |
| Y54 |
Right rear axle damping valve unit |
64 L |
| Y54x1 |
Damping valve unit connector |
63 J |
| Y54y1 |
Solenoid valve 1, rear right |
63 L |
| Y54y2 |
Solenoid valve 2, rear right |
64 L |
| Z204/4 |
Circuit 31 right footwell voltage distributor connector |
6 L |
| Z56/13 |
Left rear air suspension valve engine compartment solder point |
25 L |
| Z56/14 |
Right rear air suspension valve engine compartment solder point |
27 L |
| Z56/15 |
Rear air suspension valve engine compartment solder point (-) |
26 L |
