| A0 |
Color code key |
40L |
| A45 |
Fanfare horns and airbag clock spring contact |
19J |
| B48/7 |
Driver door pressure sensor |
27L |
| B48/8 |
Front passenger door pressure sensor |
29L |
| K88 |
Pyrotechnical separator |
32L |
| N10/8 |
Rear SAM control unit |
15L |
| N2/7 |
Restraint systems control unit |
20A |
| N2/7 |
Restraint systems control unit |
27A |
| N2/7 |
Restraint systems control unit |
12A |
| N3/10 |
ME-SFI [ME] control unit |
3L |
| N3/10 |
ME-SFI [ME] control unit |
2L |
| N3/10 |
ME-SFI [ME] control unit |
11L |
| N3/9 |
CDI control unit |
3L |
| N3/9 |
CDI control unit |
7L |
| N80 |
Steering column module |
19L |
| R12/13 |
Driver airbag ignition squib 1 |
23L |
| R12/14 |
Driver airbag ignition squib 2 |
22L |
| R12/4 |
Front passenger airbag squib 1 |
24L |
| R12/5 |
Front passenger airbag squib 2 |
25L |
| U1010 |
Valid for engine 642.870 BLUETEC |
1D |
| U1011 |
Valid for engine 642.872 |
5E |
| U1018 |
Valid for gasoline engine 276 |
9D |
| U12 |
Valid for left-hand drive vehicles |
26A |
| U127 |
Valid for engine 272, engine 273 KE |
1D |
| U13 |
Valid for right-hand drive vehicles |
28A |
| U152 |
Valid for engine 156 |
1D |
| U880 |
Valid for engine 642 |
5D |
| W26 |
Ground (restraint systems control unit) |
28L |
| X25/2 |
Engine compartment/interior compartment connector |
3H |
| X25/2 |
Engine compartment/interior compartment connector |
7H |
| X25/2 |
Engine compartment/interior compartment connector |
11H |
| X35/1 |
Left front door separation point |
26G |
| X35/2 |
Right front door separation point |
29G |
| X99/15 |
Airbag separation point |
23G |
| Z6/14 |
Circuit 31 ground connector sleeve (left belt buckle) |
28G |
