| B48/11 |
Left front WSS (Weight Sensing System) sensor |
9 L |
| B48/12 |
Right front WSS (Weight Sensing System) sensor |
11 L |
| B48/13 |
Left rear WSS (Weight Sensing System) sensor |
12 L |
| B48/14 |
Right rear WSS (Weight Sensing System) sensor |
14 L |
| F33 |
Battery compartment prefuse box |
3 L |
| F33f83 |
Fuse 83 |
3 J |
| N2/13 |
WSS (Weight Sensing System) control unit |
4 A |
| N2/13 |
WSS (Weight Sensing System) control unit |
12 A |
| W26 |
Ground (restraint systems control unit) |
1 L |
| X30/6 |
Cockpit voltage distributor (CAN) connector |
7 L |
| X55/4 |
Right front seat contacting strip |
1 E |
| Z6/14 |
Circuit 31 ground connector sleeve (left belt buckle) |
1 H |
