| E17/17 |
Right rear footwell lamp |
66 L |
| E17/18 |
Left rear footwell lamp |
7 L |
| F33 |
Battery compartment prefuse box |
41 A |
| F33 |
Battery compartment prefuse box |
46 A |
| F4 |
Load compartment fuse and relay box |
27 A |
| F4 |
Load compartment fuse and relay box |
59 A |
| F58 |
Engine compartment fuse and relay box |
45 L |
| K24/1 |
Driver seat adjustment comfort relay |
26 L |
| K24/2 |
Front passenger seat adjustment comfort relay |
30 L |
| N10 |
Front SAM control unit |
5 A |
| N10 |
Front SAM control unit |
64 A |
| N10 |
Front SAM control unit |
67 A |
| N10/8 |
Rear SAM control unit |
32 A |
| N2/13 |
WSS (Weight Sensing System) control unit |
38 L |
| N2/7 |
Restraint systems control unit |
16 A |
| N2/7 |
Restraint systems control unit |
21 A |
| N2/7 |
Restraint systems control unit |
51 A |
| N2/7 |
Restraint systems control unit |
56 A |
| N25/7 |
HS [SIH], seat ventilation and steering wheel heater control unit |
11 A |
| N25/7 |
HS [SIH], seat ventilation and steering wheel heater control unit |
70 A |
| N29/5 |
Left front seat ventilation blower regulator |
11 L |
| N29/6 |
Right front seat ventilation blower regulator |
69 L |
| R12/10 |
Front passenger sidebag squib |
50 L |
| R12/9 |
Driver sidebag squib |
15 L |
| R13/1 |
Left front seat heated cushion |
4 L |
| R13/2 |
Left front backrest heated cushion |
2 L |
| R13/2x1 |
Left front backrest heated cushion connector |
1 J |
| R13/3 |
Right front seat heated cushion |
64 L |
| R13/4 |
Right front backrest heated cushion |
62 L |
| R13/4x1 |
Right front backrest heater element connector |
62 J |
| R46 |
Driver buckle ETR squib |
17 L |
| R46/1 |
Front passenger buckle ETR squib |
52 L |
| S22 |
Driver seat adjustment switch |
28 L |
| S23 |
Front passenger seat adjustment switch |
33 L |
| S68/1 |
Driver seat belt buckle and seat belt warning switch |
21 L |
| S68/1x1 |
Left front seat belt buckle and seat belt warning switch connector |
20 J |
| S68/1x1 |
Left front seat belt buckle and seat belt warning switch connector |
55 J |
| S68/2 |
Front passenger seat belt buckle and seat belt warning switch |
56 L |
| U284 |
Valid for fully electric seat adjustment |
25 A |
| U656 |
Valid for interior light package |
6 A |
| U656 |
Valid for interior light package |
66 A |
| U831 |
Valid for NECK-PRO head restraints |
18 A |
| U831 |
Valid for NECK-PRO head restraints |
53 A |
| U931 |
Not valid for engine 642 BLUETEC |
43 A |
| W15/1 |
Ground (right footwell) |
34 A |
| W15/2 |
Ground (left footwell) |
28 C |
| W26 |
Ground (restraint systems control unit) |
23 H |
| W26 |
Ground (restraint systems control unit) |
35 A |
| W26 |
Ground (restraint systems control unit) |
58 H |
| X30/6 |
Cockpit voltage distributor (CAN) connector |
38 A |
| X55/3 |
Left front seat contacting strip |
1 H |
| X55/3 |
Left front seat contacting strip |
6 H |
| X55/3 |
Left front seat contacting strip |
10 H |
| X55/3 |
Left front seat contacting strip |
14 F |
| X55/3 |
Left front seat contacting strip |
20 E |
| X55/3 |
Left front seat contacting strip |
25 E |
| X55/4 |
Right front seat contacting strip |
29 E |
| X55/4 |
Right front seat contacting strip |
35 F |
| X55/4 |
Right front seat contacting strip |
49 F |
| X55/4 |
Right front seat contacting strip |
55 E |
| X55/4 |
Right front seat contacting strip |
61 H |
| X55/4 |
Right front seat contacting strip |
66 H |
| X55/4 |
Right front seat contacting strip |
69 H |
| Y24/12 |
Driver NECK-PRO head restraint solenoid |
18 L |
| Y24/12x1 |
Driver NECK-PRO head restraint solenoid connector |
18 K |
| Y24/12x1 |
Driver NECK-PRO head restraint solenoid connector |
53 K |
| Y24/13 |
Front passenger NECK-PRO head restraint solenoid |
53 L |
| Z204/4 |
Circuit 31 right footwell voltage distributor connector |
49 A |
| Z204/4 |
Circuit 31 right footwell voltage distributor connector |
62 A |
| Z204/4 |
Circuit 31 right footwell voltage distributor connector |
67 C |
| Z204/5 |
Circuit 31 left footwell voltage distributor connector (1) |
2 A |
| Z204/5 |
Circuit 31 left footwell voltage distributor connector (1) |
7 C |
| Z204/5 |
Circuit 31 left footwell voltage distributor connector (1) |
14 A |
| Z54/7 |
Footwell lamps connector sleeve |
6 E |
| Z54/7 |
Footwell lamps connector sleeve |
66 E |
| Z6/14 |
Circuit 31 ground connector sleeve (left belt buckle) |
35 C |
| Z6/15 |
Circuit 31 ground connector sleeve (right belt buckle) |
22 E |
| Z6/15 |
Circuit 31 ground connector sleeve (right belt buckle) |
58 E |
| Z61/16 |
Convenience relay circuit 30 connector sleeve |
32 H |
| Z61/17 |
Convenience relay circuit 31 connector sleeve |
27 H |
