| A0 |
Color code key |
48L |
| A6 |
STH heater unit |
20L |
| CAN B |
Interior CAN |
2K |
| N110 |
Weight Sensing System (WSS) control unit |
13L |
| N121 |
TLC [HDS] control unit |
32L |
| N22/6 |
Rear control unit |
6L |
| N32/2 |
Right front seat control unit |
9L |
| N62 |
PTS control unit |
24L |
| N62 |
PTS control unit |
24L |
| N69/2 |
Right door control unit |
17L |
| N70 |
Overhead control panel control unit |
28L |
| N70 |
Overhead control panel control unit |
40L |
| N88 |
TPM [RDK] control unit |
36L |
| U1 |
Valid for {{USA}} |
11E |
| U538 |
Valid for Parktronic System |
22G |
| U538 |
Valid for Parktronic System |
22G |
| U579 |
Valid for stationary heater (STH) |
19G |
| U645 |
Valid for tire pressure monitor system |
34G |
| U658 |
Valid for remote trunk closing |
30G |
| W19 |
Ground (right front seat crossmember) |
6E |
| X25/8 |
Overhead control panel and FFS [RBA] connector |
27E |
| X25/8 |
Overhead control panel and FFS [RBA] connector |
39G |
| X28/30 |
Passenger-side FFS [RBA]/seat airbag separation point |
12H |
| X30/32 |
Left interior CAN/FFS [RBA] voltage distributor connector |
2L |
| X30/33 |
Right interior CAN/FFS [RBA] voltage distributor connector |
4A |
| X30/33 |
Right interior CAN/FFS [RBA] voltage distributor connector |
12A |
| X30/33 |
Right interior CAN/FFS [RBA] voltage distributor connector |
20A |
| X30/33 |
Right interior CAN/FFS [RBA] voltage distributor connector |
36A |
| X30/33 |
Right interior CAN/FFS [RBA] voltage distributor connector |
28A |
