| N82/1f1 |
30 |
25.0 RD |
- Front prefuse box (F32) (via on-board electrical network line pyrofuse (N82/1f1))
|
- |
| N82/1f2 |
30 |
16.0 RD |
Valid for code (597) Heated windshield (model 221):
- Heated windshield control unit (N61)
|
125 |
| N82/1f3 |
30 |
10.0 RD |
- Right instrument panel fuse box (F1/6)
|
80 |
| N82/1f4 |
30 |
16.0 RD |
- Rear SAM control unit with fuse and relay module (N10/2)
|
200 |
| N82/1f5 |
30 |
6.0 RD |
Valid for special-purpose vehicles (model 221):
- Special vehicle multifunction control unit (SVMCU [MSS]) (N26/9)
|
100 |
| N82/1f6 |
30 |
16.0 RD |
- Rear SAM control unit with fuse and relay module (N10/2)
|
150 |
| N82/1f7 |
30 |
10.0 RD |
- Front SAM control unit with fuse and relay module (N10/1)
|
100 |
| N82/1f8 |
30 |
10.0 RDWH |
- Left instrument panel fuse box (F1/7)
|
80 |
| N82/1f9 |
30 |
0.75 RDGN |
- Front SAM control unit with fuse and relay module (N10/1)
|
5 |
| N82/1f10 |
30 |
0.75 RD |
Valid for code (359) TELE AID emergency call system (model 216):
- Emergency call system control unit (N123/4)
|
5 |
