| A0 |
Color code key |
72L |
| A2/12 |
Rear window antenna amplifier module |
4A |
| A2/12 |
Rear window antenna amplifier module |
13A |
| A2/12 |
Rear window antenna amplifier module |
21A |
| A2/12 |
Rear window antenna amplifier module |
29A |
| A2/12 |
Rear window antenna amplifier module |
34A |
| A2/27 |
Stationary heater antenna (Telestart) |
47L |
| A2/27x1 |
Stationary heater antenna connector (Telestart) |
47J |
| A2/49 |
Telephone and GPS antenna |
39L |
| A2/49a1 |
Telephone antenna |
38L |
| A2/49a2 |
GPS antenna |
40L |
| A2/79 |
TV antenna selector |
27L |
| A28/3 |
E-net compensator |
41A |
| A28/3 |
E-net compensator |
51A |
| A28/3 |
E-net compensator |
63A |
| A34/15 |
UHI portable CTEL holder (Universal Handy Interface) |
57L |
| A34/15x2 |
Connector 2, UPCI [UHI] portable CTEL holder (Universal Handy Interface) |
57K |
| A34/7 |
Bluetooth module |
63L |
| A34/7 |
Bluetooth module |
70L |
| A40/3 |
COMAND control unit |
22L |
| A40/3 |
COMAND control unit |
31L |
| A40/3 |
COMAND control unit |
43L |
| A40/3 |
COMAND control unit |
60L |
| A6/1 |
STH radio remote control receiver |
46L |
| A90/1 |
TV combination tuner (analog/digital) |
17L |
| N10/2 |
Rear SAM control unit with fuse and relay module |
2L |
| N10/2 |
Rear SAM control unit with fuse and relay module |
54L |
| N10/2 |
Rear SAM control unit with fuse and relay module |
67L |
| N10/2f129 |
Fuse 129 |
65K |
| N123/1 |
Universal Portable CTEL Interface (UPCI [UHI]) control unit |
50L |
| N69/5 |
KEYLESS-GO control unit |
35L |
| N87/8 |
High-definition tuner control unit |
11L |
| N93/1 |
Audio tuner control unit |
7L |
| U1 |
Valid for {{USA}} |
9F |
| U1 |
Valid for {{USA}} |
6F |
| U193 |
Valid for TV and Video |
13F |
| U193 |
Valid for TV and Video |
20F |
| U2 |
Valid for all except{{USA}} |
6F |
| U43 |
Valid for ECE |
41E |
| U43 |
Valid for ECE |
41F |
| U52 |
Valid for {{Japan}} |
41E |
| U52 |
Valid for {{Japan}} |
21F |
| U52 |
Valid for {{Japan}} |
36A |
| U52 |
Valid for {{Japan}} |
43F |
| U801 |
Valid for UHI (Universal Portable CTEL Interface) |
49F |
| U82 |
Valid for KEYLESS GO |
33F |
| W6 |
Ground (left wheelhouse in luggage compartment) |
63E |
| W6 |
Ground (left wheelhouse in luggage compartment) |
49E |
| X1/16 |
Roof antenna connector |
1G |
| X1/16 |
Roof antenna connector |
14H |
| X1/16 |
Roof antenna connector |
22H |
| X1/16 |
Roof antenna connector |
30H |
| X39/35 |
GPS antenna connector |
41H |
| X39/37 |
CTEL separation point |
37A |
| X39/39 |
Handy connector |
57H |
| X39/39 |
Handy connector |
57E |
| Z6/56 |
Circuit 31 connector sleeve |
63G |
| Z6/56 |
Circuit 31 connector sleeve |
50E |
| Z7/40 |
Tml. 30 connector sleeve |
22J |
| Z7/40 |
Tml. 30 connector sleeve |
54G |
| Z7/40 |
Tml. 30 connector sleeve |
64G |
| Z99/10 |
E-net compensator connector sleeve |
59G |
