| A0 |
Explanation of color codes |
56L |
| A2/49 |
Telephone and GPS antenna |
23L |
| A2/49a2 |
GPS antenna |
22L |
| A2/5 |
Antenna splitter |
28L |
| A40/3 |
COMAND control unit |
4A |
| A40/3 |
COMAND control unit |
12A |
| A40/3 |
COMAND control unit |
20A |
| A40/3 |
COMAND control unit |
28A |
| A40/3 |
COMAND control unit |
36A |
| A40/3 |
COMAND control unit |
44A |
| A40/3 |
COMAND control unit |
49A |
| A40/8 |
COMAND display |
32L |
| A40/8 |
COMAND display |
39L |
| A90/1 |
TV combination tuner (analog/digital) |
49L |
| N10/1 |
Front SAM control module with fuse and relay module |
41L |
| N10/2 |
Rear SAM control module with fuse and relay module |
2L |
| N66/10 |
Backup camera voltage supply module |
6L |
| N66/2 |
Reverse camera control module |
6L |
| U1 |
Valid for {{USA}} |
27F |
| U12 |
Valid for left-hand steering |
37G |
| U13 |
Valid for right-hand steering |
37G |
| U193 |
Valid for TV and Video |
47F |
| U43 |
Valid for ECE |
25F |
| U899 |
Valid for backup camera |
5F |
| W15 |
Ground (electronics power ground) |
37G |
| W18 |
Ground (left front seat crossmember) |
3E |
| W34 |
Ground (left footwell) |
37G |
| W43 |
Ground (reference, image transmission systems) |
4E |
| W43 |
Ground (reference, image transmission systems) |
36G |
| X18 |
Cockpit wiring harness and FFS [RBA] connector |
13E |
| X18 |
Cockpit wiring harness and FFS [RBA] connector |
38G |
| X30/20 |
Central CAN voltage distributor connector |
13L |
| X30/35 |
Telematics CAN voltage distributor connector |
10L |
| X30/35 |
Telematics CAN voltage distributor connector |
45L |
| X39/35 |
GPS antenna connector |
25J |
| X39/45 |
Walkman separation point |
15E |
| X39/45 |
Walkman separation point |
17L |
| Z20/22 |
Cable end not insulated, placed inside insulated tubing |
30C |
| Z20/23 |
Cable end not insulated, placed inside insulated tubing |
30J |
