| F1 |
Fuse box |
7 B |
| F1 |
Fuse box |
23 B |
| F1f10 |
Fuse 10 |
7 C |
| F1f10 |
Fuse 10 |
24 B |
| F1f12 |
Fuse 12 |
24 B |
| F1f8 |
Fuse 8 |
8 C |
| K24 |
Comfort shift relay |
14 D |
| K26 |
Wiper system relay |
13 A |
| K26 |
Wiper system relay |
23 K |
| K26/4 |
Rear wiper system relay |
19 A |
| M5/1 |
Windshield washer fluid pump |
16 L |
| M6/1 |
Wiper motor |
8 L |
| M6/4 |
Rear-end door wiper motor |
20 L |
| M6/4x1 |
Rear-end door wiper motor connector |
19 J |
| N36 |
Transmission output speed sensor ballast |
25 C |
| R2/2 |
Left heated windshield washer nozzle |
4 G |
| R2/3 |
Right washer nozzle heater |
2 G |
| R2/3 |
Right washer nozzle heater |
22 A |
| S16/10s1 |
Backup lamp switch |
10 L |
| S2/1 |
Ignition/starter switch |
4 A |
| S2/1 |
Ignition/starter switch |
27 A |
| S4 |
Combination switch |
12 L |
| S4s4 |
Wash switch with one-touch wiping |
11 H |
| S4s7 |
Intermittent wipe switch |
12 K |
| S4s8 |
Slow wipe switch |
12 K |
| S4s9 |
Fast wipe switch |
12 K |
| S4x1 |
Combination switch connector |
11 G |
| S78 |
Rear window wipe/wash switch |
27 E |
| S78/1 |
Rear-end door wiper switch I, continuous wiping II, intermittent wiping |
23 E |
| S9/1 |
Stop lamp switch |
5 B |
| S9/1 |
Stop lamp switch |
22 A |
| U12 |
Valid for left-hand drive vehicles |
2 L |
| U12 |
Valid for left-hand drive vehicles |
5 B |
| U12 |
Valid for left-hand drive vehicles |
8 F |
| U12 |
Valid for left-hand drive vehicles |
10 H |
| U12 |
Valid for left-hand drive vehicles |
13 C |
| U12 |
Valid for left-hand drive vehicles |
21 A |
| U12 |
Valid for left-hand drive vehicles |
24 H |
| U12 |
Valid for left-hand drive vehicles |
28 H |
| U13 |
Valid for right-hand drive vehicles |
2 L |
| U13 |
Valid for right-hand drive vehicles |
6 B |
| U13 |
Valid for right-hand drive vehicles |
9 F |
| U13 |
Valid for right-hand drive vehicles |
10 H |
| U13 |
Valid for right-hand drive vehicles |
15 E |
| U13 |
Valid for right-hand drive vehicles |
22 E |
| U13 |
Valid for right-hand drive vehicles |
23 H |
| U13 |
Valid for right-hand drive vehicles |
23 A |
| U13 |
Valid for right-hand drive vehicles |
27 H |
| U236 |
Valid for rear-end door wiper system |
18 A |
| W12 |
Ground (center console) |
13 D |
| W12 |
Ground (center console) |
21 A |
| W12 |
Ground (center console) |
28 L |
| W29/1 |
Ground (left A-pillar) |
2 K |
| W29/1 |
Ground (left A-pillar) |
9 G |
| W29/1 |
Ground (left A-pillar) |
14 D |
| W29/2 |
Ground (right A-pillar) |
24 K |
| W29/5 |
Ground (left rear pillar) |
20 H |
| W29/5 |
Ground (left rear pillar) |
27 L |
| W29/7 |
Ground (steering column) |
8 G |
| W3/1 |
Ground (right front wheelhouse) |
2 K |
| X11/29 |
Fuse test connector |
25 K |
| X12/3 |
Circuit 30, 15, 61 terminal block (3-pin) |
10 A |
| X6 |
Circuit 58 terminal block (2-pin) |
29 A |
| X8/3 |
Rear-end door wiper motor connector |
13 E |
| X8/3 |
Rear-end door wiper motor connector |
17 G |
| X8/3 |
Rear-end door wiper motor connector |
25 H |
| Y68 |
Differential lock solenoid valve (longitudinal equalization) |
9 L |
| Z50/1 |
Connector sleeve 1 |
6 B |
| Z50/1 |
Connector sleeve 1 |
23 A |
