C32 AMG, C240 Sedan, C240 Sedan 4MATIC & C320 Sedan 4MATIC

WARNING: This page does not describe the selected car, but rather 16 other vehicles, including the 2004 Mercedes-Benz CLK55, 2004 Mercedes-Benz CLK500, 2004 Mercedes-Benz CLK320, 2004 Mercedes-Benz C320, and 2004 Mercedes-Benz C32. However, it is still accessible from the selected car via links, so may be relevant.

NOTE: For model to chassis identification, see MODEL IDENTIFICATION - 203 CHASSIS table under MODEL IDENTIFICATION.

To adjust hood gap, see ADJUSTING HOOD GAP (C32 AMG, C240 SEDAN, C240 SEDAN 4MATIC & C320 SEDAN 4MATIC) table.

ADJUSTING HOOD GAP (C32 AMG, C240 SEDAN, C240 SEDAN 4MATIC & C320 SEDAN 4MATIC)

Gap Dimension

Hood Gap

Hood-To-Fender

Dimension "A" ⁽¹⁾

2.5-4.5 mm

Hood-To-Headlamp

Dimension "R" ⁽¹⁾

3.5-5.54 mm

⁽¹⁾	See Fig 1 .

Fig 1: Adjusting Hood Gap (C32 AMG, C240 Sedan, C240 Sedan 4MATIC & C320 Sedan 4MATIC)

Courtesy of MERCEDES-BENZ OF NORTH AMERICA.
