Location and assignment of Z connector sleeves (connectors and wiring harness) - trunk left - GF00.19-P-3000-06FAA

WARNING: This page is about a different car, the 2011 Mercedes-Benz C300, 2010 Mercedes-Benz C300, 2009 Mercedes-Benz C300, and 2008 Mercedes-Benz C300. However, it is still accessible from the selected car via links, so may be relevant.

Model 204

Fig 1: Locating Trunk Z Connector Sleeves - Left
G07071109Courtesy of MERCEDES-BENZ USA
