Remove/install operating lever for mechanically swiveling trailer hitch - AR31.11-P-8010M
MODEL 215.375 378220.026 /028 /063 /065 /070 /075 /126 /128 /165 /170 /175 /178 1# up to 31.8.02 with CODE (550) Trailer hitch except CODE (772) AMG styling package - front spoiler, side skirts and rear apron Mechanically swiveling trailer hitch
MODEL 215.375 376 378220.025 /026 /028 /063 /065 /067 /070 /075 /083 /084 /087 /125 /126 /128 /165 /167 /170 /175 /176 /178 /183 /184 /187 1# as of 1.9.02 with CODE (550) Trailer hitch except CODE (855) TELE AID except CODE (772) AMG styling package - front spoiler, side skirts and rear apron except CODE (979) Special protection version Mechanically swiveling trailer hitch
Shown on Model 220
| Remove/install | |||
| Risk of explosion from explosive gas. Risk of poisoning and caustic burns from swallowing battery electrolyte. Risk of injury through burns to skin and eyes from battery acid or when handling damaged lead-acid batteries | No fire, sparks, open flames or smoking. Wear protective gloves, acid-resistant clothing and safety glasses. Pour battery electrolyte only into suitable and appropriately marked containers. | AS54.10-Z-0001-01A | |
| 1 | Disconnect ground cable of battery | AR54.10-P-0003I | |
| Notes on battery | All models | AH54.10-P-0001-01A | |
| Notes on AGM battery | Model 215 as of 1.1.01. Model 220.028 with CODE (450) Taxi version. Models 220.070/075/175/178/875/878 as of 1.1.01. |
AH54.10-P-0002-01A | |
| 2 | Unlock ball neck | ||
| Unlocking device for trailer hitch release cable. | WF58.50-P-3111-01M | ||
| Unlock ball neck if operating lever is damaged. | AR31.11-P-8000-03M | ||
| 3 | Unscrew bolts (1) and fold down trailer hitch release (A63) | ||
| 4 | Separate electrical connectors (2) | ||
| 5 | Unhook cable (3) from guide (see arrow) of trailer hitch (A63) and remove trailer hitch release (A63) | ||
| 6 | Install in the reverse order | ||
| 7 | Carry out function check of mechanically swiveling trailer hitch | AR31.19-P-1450M |
