Hook for aligning inner panel - WF58.50-P-4340-01P

  1. Fabricate hook for pulling out inner panel with the following dimensions. For this purpose use 10 mm dia. steel rod.
    Fig 1: Identifying Hook For Aligning Inner Panel Dimensions
    G04733951
