Fuel delivery module, design - GF47.20-P-4101-02P
Model 203, 209
The fuel pump (M3), the right fuel level sensor (B4/2) and the splash bowl are integrated in the fuel delivery module:
- The fuel gage sensor is a lever-type sensor with sliding contacts (potentiometer)
- The fuel pump is a two-stage flow pump
- The splash bowl is a plastic housing and contains the following components
