Retrofitting CD changer in trunk - AZ82.64-P-0001-05C

Model 210.2 except code 351 in combination with Audio 10 or Audio 30 radio

1. Screw CD player with changer (A2/6) to mount (20) with 4 short screws (21).

   The maximum length of the mounting screws (21) is indicated on the CD player housing.

   Fig 1: Identifying CD Player With Changer

   Courtesy of MERCEDES-BENZ OF NORTH AMERICA.
2. Connect D2B fiber optic cable connector (22) and power supply (23).
   Fig 2: Connecting D2B Fiber Optic Cable Connector And Power Supply

   Courtesy of MERCEDES-BENZ OF NORTH AMERICA.
3. Install mount (20) and CD player with changer (A2/6) in right load compartment recess with screws (24) as shown in figure.

   Do not kink or stretch fiber optic cable!

   Routing radii must be greater than 25 mm!

   Fig 3: Identifying CD Player With Changer In Right Load Compartment Recess With Screws

   Courtesy of MERCEDES-BENZ OF NORTH AMERICA.
