Removing and installing cover below instrument panel (left) - AR68.10-P-1500N
MODEL 215
| Removal, installation | |||
| 1 | Unscrew mounting nut (1) from front cover | ||
| 2 | Slide front cover (1) out of knee guard (3) with catch lugs (2) toward front and pull out of guide (arrow) toward rear over accelerator pedal | ||
| 3 | Unclip footwell illumination from knee guard (3) and disconnect connector | ||
| 4 | Unscrew screws (4) (4 each) | ||
| 5 | Push knee guard (3) with hooks (5) (4 each) downward out of instrument panel (6) | ||
| 6 | Install in opposite order |
