Draining TIREFIT sealant out of tires - AR40.10-P-1080A

MODELS 163, 164, 168, 170, 171, 203, 209, 211, 230, 240, 414 after using TIREFIT tire sealant

Fig 1: Draining TIREFIT Sealant Out Of Tires

	Draining
	Risk of poisoning  caused by swallowing the TIREFIT emulsion. Risk of injury  caused by skin contact and eye contact with the TIREFIT emulsion. Risk of fire  caused by ignition of the TIREFIT emulsion	Do not swallow or come into contact with the TIREFIT tire sealant, which is an emulsion of rubber and terpene phenolic resin. No open fire or open light sources.	AS40.10-Z-0001-01A
1	Remove wheel.
	Remove/install wheels, rotate if necessary	Model 163	AP40.10-P-4050GH
		Models 164, 168, 170, 203, 209, 211, 230, 240, 414	AP40.10-P-4050Z
		Model 171	AP40.10-P-4050V
2	Put tire down with valve facing upwards	In order to prevent TIREFIT tire sealant (3) spraying out when unscrewing the valve element.
	TIREFIT tire sealant		AH40.10-P-0001-01A
3	Unscrew valve element from valve and release pressure from the wheel
4.1	Unscrew union nut of the valve body and press the valve body into the wheel	With tire pressure monitor, code 475
4.2	Pull valve out of the disk wheel	Without tire pressure monitor Do not damage surface of the disk wheel. Push the valve debris remaining in the valve bore of the disk wheel into the inside of the wheel.
5	Wheel with valve bore pointing downwards upright for 10 minutes and put down raised slightly	Raise the wheel in order to make it easier to suction off the TIREFIT tire sealant (3).
6	Attach hose (2) to empty tire sealant container (1)	Replace the original hose of the tire sealant container (1) with a hose (2) 400 mm long.
7	Compress the tire sealant container (1) and immerse hose (2) through the valve bore of the disk wheel into the TIREFIT tire sealant (3)
8	Reduce pressure on the tire sealant container (1) and suction off TIREFIT tire sealant (3)	Position tire sealant container (1) under the wheel in order to make it easier to suction off the TIREFIT tire sealant (3). Approx 90 % of the TIREFIT tire sealant (3) is removed.
9.1	Bore the tire tread with a spiral drill (10 mm dia.) and allow TIREFIT tire sealant (3) to flow into a suitable container	If an empty tire sealant container (1) is not available
	Clean
10	Clean disk wheel	Remove the remains of the TIREFIT tire sealant (3) using a damp cloth
11.1	Replace TPM wheel sensor	With tire pressure monitor code 475 (Beru system only) In the process observe tightening torques for different gasket versions, see: ↓	BT40.15-P-0080-01A
		Valve body gasket modified.	AR40.15-P-0080A
12	Replace tires		AR40.10-P-1030A
13	Place new TIREFIT tire repair kit (3) in the vehicle	See: ↓ TIREFIT tire sealant - check expiry date	AP40.10-P-4054R
