Antenna system (AS) test diagram - AD82.62-P-2000-02D
Antenna system (AS) test diagram - AD82.62-P-2000-02D
Model 163
Test diagram for FM/AM radio/amplifier
Model 163:
Fig 1: Antenna System (AS) Test Diagram
