Checking chart for antenna system (AS) - AD82.62-P-2000-02A
MODEL 208 (except 208.4)
MODELS 202.01/02/12 as of 01.01.97
Checking chart for radio/amplifier FM/AM
MODEL 208 (except 208.4) and MODELS 202.01/02/12 as of 01.01.97:
The figure shows the checking chart for model 208. The illustration also applies to MODELS 202.01/02/12 with rear window antenna.
