Interior motion sensor transmitter and receiver, location - GF80.50-P-4104-01D

Model 202 sedan, 210.0 as of 6/98, 210.2 as of 6/99, 215, 220 with interior motion sensor

Illustrated on model 210 sedan

The interior motion sensor transmitter and receiver (A26/14) is located in the middle of the headliner.

Fig 1: Identifying Interior Motion Sensor Transmitter And Receiver Location
G04635737Courtesy of MERCEDES-BENZ OF NORTH AMERICA.
