Removing tilting/sliding roof panel - AR77.20-P-1000-01EB

Electrically operated glass tilting/sliding roof (code 414a)

1. Move tilting/sliding roof panel (2) to tilted position.
2. Remove molding (5).
   NOTE: Before pulling off molding press off on outside with plastic wedge.
   Fig 1: Identifying Molding


3. Unhook rubber bellows (6) on tilting/sliding roof panel (2), unhook rail from slider (arrow) and pull off of holder (8).
   Fig 2: Removing Rail From Slider


4. Screw off nuts (3).
5. Pry out tilting/sliding roof panel (2).
6. Actuate sliding roof switch in closing direction until sliding roof drive switches off.
   Fig 3: Identifying Tilting/Sliding Roof Panel Nuts
