Installing cover - AR77.20-P-0500-02EB

Electrically operated glass tilting/sliding roof (code 414a)

1. Hook rail of rubber bellows (5) into slider (arrow).
2. Open tilting/sliding roof.
3. Install cover (2) and slide all the way back.
   Fig 1: Identifying Rubber Bellows
