Check setting of windshield washer system spray nozzles - AP82.35-P-8252-01R

Fig 1: Identifying Adjusting Tool (110 589 02 63 00)

Courtesy of MERCEDES-BENZ OF NORTH AMERICA.

1. Check setting of windshield washer system spray nozzles and correct with suitable adjusting tool if necessary.

   The spray jet must hit the windshield in the marked area.

   Fig 2: Identifying Windshield Washer System Nozzles Spray Position

   Courtesy of MERCEDES-BENZ OF NORTH AMERICA.
