Removal and installation of bottom sections of sound proofing capsule - ra94001405305x(5305)

WARNING: This page does not describe the selected car, but rather 42 other vehicles, including the 1999 Mercedes-Benz S600, 1999 Mercedes-Benz S500, 1999 Mercedes-Benz S420, 1999 Mercedes-Benz S320, and 1999 Mercedes-Benz CL600. However, it is still accessible from the selected car via links, so may be relevant.

Model 140.1

Preliminary work:

Model 140.1

Fig 1: Locating Front Bottom Section Of Sound Proofing Capsule Mounting Bolts

G05438078

Courtesy of MERCEDES-BENZ OF NORTH AMERICA.

Front bottom section of sound proofing capsule

Arrow, mounting bolts

Fig 2: Locating Center Bottom Section Of Sound Proofing Capsule Mounting Bolts

G05438082

Courtesy of MERCEDES-BENZ OF NORTH AMERICA.

Center bottom section of sound proofing capsule

Arrow, mounting bolts

Fig 3: Locating Rear Bottom Section Of Sound Proofing Capsule Mounting Bolts

G05441502

Courtesy of MERCEDES-BENZ OF NORTH AMERICA.

Rear bottom section of sound proofing capsule

Arrow, mounting bolts

Press front bottom section of sound-proofing capsule (1) upward; the edge of the side sections (3) must engage around the bottom section (1).

Fig 4: Pressing Front Bottom Section Of Sound-Proofing Capsule Upward

G05441499

Courtesy of MERCEDES-BENZ OF NORTH AMERICA.
