Setting mileage - ra54001405345x(5345)

WARNING: This page does not describe the selected car, but rather 42 other vehicles, including the 1999 Mercedes-Benz S600, 1999 Mercedes-Benz S500, 1999 Mercedes-Benz S420, 1999 Mercedes-Benz S320, and 1999 Mercedes-Benz CL600. However, it is still accessible from the selected car via links, so may be relevant.

A. Vehicles as of approx.11/93, up to 05/96, B. Vehicles as of approx.06/96 Model 140 (except USA)

Vehicles as of approx. 11/93 up to approx. 05/96

Fig 1: Identifying Multimeter

Courtesy of MERCEDES-BENZ OF NORTH AMERICA.

This setting is possible only once during the first 300 km/miles or for during the first 10 km (total mileage reading).

PREPARATIONS FOR SETTING

Key in steering wheel lock	turn to position "2" (indicator and warning lamps "ON").
Adjustment knob (1)	press and hold.
	A signal tone sounds after approx. 10 s, the display is reset to 000000.
Key in steering wheel lock	turn to position "0" and then back to position "2".
	The word "Prog" appears on the trip odometer display. 0 - - - - - appears on the total mileage display.
Adjustment knob (1)	release.

ADJUSTMENT

Adjustment knob (2)	pull out and turn to left in direction of arrow. The number in position 1 is set to 1.
Adjustment knob (2)	release and pull out again then turn to left in direction of arrow. The number is set to 2. Repeat this step until the desired number is set. 9 is followed by 0 without a carry-over to the second position. NOTE: The number 0 must be set following the number 9.
Adjustment knob (2)	pull out and turn to the right opposite the direction indicated by the arrow. The number 0 appears in the next position. Set the next positions and numbers as described. NOTE: Only even numbers such as 0, 2 ..... can be set in position 6.

STORING TOTAL MILEAGE

Adjustment knob (1)	press and turn key in steering wheel lock to position "0".
Adjustment knob (1)	release.

CHECK SETTING

Key in steering wheel lock

turn to position "2". The total mileage set previously should be displayed.

NOTE: If entry is incomplete or a total mileage < 300 km/miles or 10 km for

is entered, the counter is reset to 000000 during the storage operation.

Repeat setting procedure.

Vehicles as of approx. 06/96
NOTE: On vehicles as of approx. 06/96 the odometer can be set with the HHT. See Diagnosis Manual.

Instrument clusters capable of being set with the HHT can be identified as follows: When the door is opened the display in the instrument cluster comes on.
