Rear Axle Carrier: Installation
To install rear axle, reverse removal procedure.
TIGHTENING SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | ||
|---|---|---|---|
| Axle Shaft-to-Axle Shaft Flange | 69 (94) | ||
| Brake Caliper Bolts | 23-29 (31-39) | ||
| Differential-to-Rear Axle Carrier | 72 (98) | ||
| Drive Shaft Clamp Nut | |||
| 2-Piece | 145 (197) | ||
| 3-Piece | |||
| Front | 23-29 (31-39) | ||
| Rear | 145 (197) | ||
| Front Rubber Mounts-to-Frame | 29 (39) | ||
| Rear Rubber Mount-to-End Cover | 101 (137) | ||
| Rear Rubber Mount-to-Frame | 18 (24) | ||
| Semi-Trailing Arm-to-Rear | |||
| Axle Carrier | 87 (118) | ||
| Shock Absorber Lower Mount | 33 (45) | ||
| Supporting Plate-to-Frame | 23-29 (31-39) | ||
| Torsion Bar Bearing Bolts | 47 (64) | ||
| Torsion Bar Connecting Rod Ball Joints | 33 (45) | ||
