Generator Drive Belt
WARNING: This page is about a different variant/trim than selected.
NOTE:
- The generator drive belt does not have to be replaced because fraying of the generator drive belt does not affect the performance.
- Inspect the inner and outer sides of the belt for wear, damage, or cracks visually or by touching with a hand.
- If any minor wear, damage, or crack is found, replace the generator drive belt. (See DRIVE BELT REMOVAL/INSTALLATION [PYUL] )
- Inspect the drive belt tension.
- If there is insufficient tension, adjust it.
- If the adjustment does not provide enough tension, replace the generator drive belt. (See DRIVE BELT REMOVAL/INSTALLATION [PYUL] )
- If there is insufficient tension, adjust it.
