Water hose installation note

  1. Install the water hose as shown in the figure.
G16702181Courtesy of MAZDA MOTORS CORP.
SYMBOL AND CONTENT DESCRIPTION

Symbol Content
0-4 mm {0-0.1 in}


  1. Install the water hose as shown in the figure.
G16702182Courtesy of MAZDA MOTORS CORP.
SYMBOL AND CONTENT DESCRIPTION

Symbol Content
0-4 mm {0-0.1 in}
