Active Driving Display Removal/Installation [L.H.D.]
>>
Remove Rear Console
>>
Rear console removal note
Rear console removal note
Remove the rear console as shown in the figure below.
the figure below shows the left side (same as right side).
Courtesy of MAZDA MOTORS CORP.
Courtesy of MAZDA MOTORS CORP.
