On-Board Diagnostics - CMU (2 Of 2)
>>
DTC B1A11-2B: Rear Door Speaker (LH) Audio Output Circuit Malfunction
>>
System Wiring Diagram
System Wiring Diagram
Courtesy of MAZDA MOTORS CORP.
COMPONENT OPERATIONS
Component No
Refer to
1
Audio amplifier
2
Rear door speaker (LH)
Courtesy of MAZDA MOTORS CORP.
