DTC P2530-00: Ignition Switch Stuck Off: Outline
WARNING: This page is about a different variant/trim than selected.
DTC P2530:00 (TCM, EV6A-EL, EV6AX-EL, US) DETECTION CONDITION AND POSSIBLE CAUSE
| System malfunction location |
Ignition switch stuck off |
| Detection condition |
- If the IG ON time count of the instrument cluster proceeds 5 s under the following condition:
- Ignition switch signal off
|
| Fail-safe |
|
| Possible cause |
- Body control module (BCM) malfunction
- Ignition switch signal output stuck off
- Wiring harness malfunction
- Short or open signal in ignition switch
- Ignition switch signal terminal malfunction
- Control valve body malfunction
- Ignition switch signal terminal pin deformity
|
 Courtesy of MAZDA MOTORS CORP.
|
