DTC U0336:00 [Pcm (SKYACTIV-G)]: Outline

WARNING: This page is about a different variant/trim than selected.

DTC U0336:00 (PCM, SKYACTIV-G) DETECTION CONDITION AND POSSIBLE CAUSE

System malfunction location	Sophisticated Airbag Sensor (SAS) control module error
Detection condition	When any of the following conditions is met: CAN communication line malfunction between Sophisticated Airbag Sensor (SAS) control module and PCM Sophisticated Airbag Sensor (SAS) control module internal malfunction
Fail-safe	Not applicable
Possible cause	CAN drive error (Sophisticated Airbag Sensor (SAS) control module or PCM) CAN communication line malfunction between Sophisticated Airbag Sensor (SAS) control module and PCM Sophisticated Airbag Sensor (SAS) control module connector or terminals malfunction PCM connector or terminals malfunction Sophisticated Airbag Sensor (SAS) control module malfunction PCM malfunction
Courtesy of MAZDA MOTORS CORP.
