DTC B00D5-01: Pad Off Indicator Circuit Open Circuit Or Short To Power Supply (Airbag) (Us): Outline
WARNING: This page is about a different car, the 2020 Mazda CX-30. However, it is still accessible from the selected car via links, so may be relevant.
DTC B00D5:01 (AIRBAG) (US) DETECTION CONDITION AND POSSIBLE CAUSE
| System malfunction location |
PAD OFF indicator circuit open circuit or short to power supply |
| Detection condition |
WARNING:
- Detection conditions are for understanding the DTC outline before performing an inspection. Performing an inspection according to only the detection conditions may cause injury due to an operating error, or damage the system. When performing an inspection, always follow the inspection procedure.
- There is an open circuit or short circuit in PAD indicator request signal circuit.
|
| Fail-safe |
|
| Possible cause |
- Body control module (BCM) detects DTC
- Indicator unit connector malfunction
- Body control module (BCM) connector malfunction
- Short to ground in indicator unit signal circuit
- Open circuit in indicator unit signal circuit
- Short to power supply in indicator unit signal circuit
- Indicator unit malfunction
- SAS control module malfunction
|
 Courtesy of MAZDA MOTORS CORP.
|
