DTC U0323-00: Instrument Cluster Error: Outline

WARNING: This page is about a different car, the 2020 Mazda CX-30. However, it is still accessible from the selected car via links, so may be relevant.

DTC U0323:00 (PCM, SKYACTIV-G) DETECTION CONDITION AND POSSIBLE CAUSE

System malfunction location	Instrument cluster error
Detection condition	When any of the following conditions is met: CAN communication line malfunction between instrument cluster and PCM Instrument cluster internal malfunction
Fail-safe	Not applicable
Possible cause	CAN drive error (instrument cluster or PCM) CAN communication line malfunction between instrument cluster and PCM Instrument cluster connector or terminals malfunction PCM connector or terminals malfunction Instrument cluster malfunction PCM malfunction
Courtesy of MAZDA MOTORS CORP.MAZDA MOTORS CORP. Courtesy of MAZDA MOTORS CORP.MAZDA MOTORS CORP.
