DTC C2006-71: Electric Parking Brake Motor Gear Unit (LH) Sticking [DSC HU/Cm]: Outline

DTC C2006:71 (DSC HU/CM) DETECTION CONDITION AND POSSIBLE CAUSE

System malfunction location	Electric parking brake motor gear unit (LH) sticking
Detection condition	The DSC HU/CM detects that the current flowing through the electric parking brake motor gear unit (LH) circuit is the specification or more.
Fail-safe	Refer to "DTC Table" and "Fail-safe Function Malfunction Contents Table". (See DTC TABLE [DSC HU/CM (US)] .)
Possible cause	Electric parking brake motor gear unit (LH) connector or terminal malfunction DSC HU/CM connector or terminals malfunction Open circuit in electric parking brake motor gear unit (LH) signal circuit Electric parking brake motor gear unit (LH) malfunction DSC HU/CM malfunction
