DTC B13F2-09: Power Window Motor (Passenger's Side) Malfunction [(BCM) (Us)]: Outline

DTC B13F2:09 (BODY CONTROL MODULE - US) DETECTION CONDITION AND POSSIBLE CAUSE

System malfunction location	Power window motor (passenger's side) malfunction
Detection condition	The door-electrical supply unit (passenger's side) detects the power window motor (passenger's side) malfunction.
Fail-safe	Not applicable
Possible cause	Power window motor (passenger's side) connector or terminal malfunction Door-electrical supply unit (passenger's side) connector or terminal malfunction Short to ground in power window motor (passenger's side) signal circuit Short to power supply in power window motor (passenger's side) signal circuit Open circuit in power window motor (passenger's side) signal circuit Power window motor (passenger's side) malfunction Door-electrical supply unit (passenger's side) malfunction Body control module (BCM) malfunction
Courtesy of MAZDA MOTORS CORP.
