Front Door Garnish Removal/Installation

WARNING: This page is about a different car, the 2016 Mazda CX-5. However, it is still accessible from the selected car via links, so may be relevant.

WARNING:

Using a utility knife with bare hands can cause injury. Always wear gloves when using a utility knife.

Using a tape-wrapped fastener remover, remove clips A in the direction of arrow (1), (2) shown in the figure.
Remove the double-sided adhesive tape in the position shown in the figure using the utility knife, remove the rear door garnish from the body.

Fig 1: Removing Rear Door Garnish From Body
Courtesy of MAZDA MOTORS CORP.
Install in the reverse order of removal.
