Instrumentation/Driver Info. Location Index: Interior

WARNING: This page is about a different car, the 2016 Mazda CX-5. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Indicator And Fuel Gauge Sender Units

Courtesy of MAZDA MOTORS CORP.

COMPONENT DESCRIPTION

1	Instrument cluster (See INSTRUMENT CLUSTER REMOVAL/INSTALLATION .) (See INSTRUMENT CLUSTER DISASSEMBLY/ASSEMBLY .) (See INSTRUMENT CLUSTER INSPECTION .) (See INSTRUMENT CLUSTER CONFIGURATION (USING READ/WRITE FUNCTION) .) (See INSTRUMENT CLUSTER CONFIGURATION (USING AS-BUILT DATA) .) (See INSTRUMENT CLUSTER OPERATION RECORD .) (See INSTRUMENTATION/DRIVER INFO. PERSONALIZATION FEATURES SETTING PROCEDURE .)
2	Indicator unit (See INDICATOR UNIT REMOVAL/INSTALLATION .) (See INDICATOR UNIT INSPECTION .)
3	Fuel gauge sender unit (See FUEL GAUGE SENDER UNIT REMOVAL/INSTALLATION [2WD] .) (See FUEL GAUGE SENDER UNIT REMOVAL/INSTALLATION [AWD] .) (See FUEL GAUGE SENDER UNIT INSPECTION [2WD] .) (See FUEL GAUGE SENDER UNIT INSPECTION [AWD] .)
