Home >> Mazda >> 2017 >> CX-3 Sport, FWD >> Repair and Diagnosis >> Accessories & Equipment >> Gauges & Instrument Panels >> Instrumentation/Driver Info >> Instrument Cluster Personalization Features Setting Procedure >> Temperature >> Using instrument cluster (without center display)

Using instrument cluster (without center display)

Fig 1: Instrument Cluster Personalization Features Setting Flow Chart

G11434425

Courtesy of MAZDA MOTORS CORP.
