Section 3 (On-Board Diagnostics - Automatic Transaxle)
>>
On-Board Diagnostic System Foreword
>>
Troubleshooting Procedure
Troubleshooting Procedure
WARNING:
This page is about a different variant/trim than selected.
Fig 1: FW6A-EL On-Board Diagnostic System Troubleshooting Procedure Flowchart
Courtesy of MAZDA MOTORS CORP.
