Tie Rod Disassembly Note

CAUTION:

If the steering rack is secured to a vise without using a cloth, the sliding surface of the steering rack could be damaged. Always use a clean cloth when securing the steering rack to the vise.
If the steering rack is secured to a vise in the incorrect position, the steering gear could fall off the vise and be damaged during the operation. Always secure the steering rack to the vise in the proper position.

Protect the steering rack tooth surface using a clean cloth and secure it using a vise.

Fig 1: Protecting Steering Rack Tooth Surface Using Clean Cloth
Remove the tie rod using the SST .

Fig 2: Removing Tie Rod Using SST
