Floor Seal Assembly Note

  1. Assemble the floor seal using the SST  and a press, steel plate.
    Fig 1: Assembling Floor Seal Using SST
    G08152235
    NOTE:
    • Set the steering gear and linkage to the press with the housing cover facing down as shown in the figure.
