DTC P0138:00, P0158:00: Notes
WARNING: This page is about a different variant/trim than selected.
| DTC P0138:00 |
P0138:00: HO2S (RH) circuit high voltage |
| DTC P0158:00 |
P0158:00: HO2S (LH) circuit high voltage |
| DETECTION CONDITION |
- P0138:00 indicates that HO2S (RH) circuit high voltage
- P0158:00 indicates that HO2S (LH) circuit high voltage
- The HO2S signals are monitored for an over voltage condition. The code is set when the HO2S signal voltage is 1.5 V or more.
|
| POSSIBLE CAUSE |
- Short to power supply in the wiring harness or HO2S
- PCM malfunction
|
 Courtesy of MAZDA MOTORS CORP.
|
