Trunk End Trim Removal/Installation

WARNING: This page is about a different car, the 2009 Mazda 6. However, it is still accessible from the selected car via links, so may be relevant.

Open the trunk lid.
Remove the trunk mat.
Remove the trunk board.
Remove the fasteners A.

Fig 1: Identifying Trunk End Trim
Courtesy of MAZDA MOTORS CORP.
Pull the trunk end trim in the direction of the arrow shown in the figure and remove it while detaching the pins B, D and clips C.
Install in the reverse order of removal.
