DTC P0711:00 [FS5A-El]: Notes

WARNING: This page is about a different car, the 2009 Mazda 6. However, it is still accessible from the selected car via links, so may be relevant.

DETECTION CONDITION AND POSSIBLE CAUSE

DTC P0711:00	TFT sensor circuit range/performance
DETECTION CONDITION	The TCM detects that input voltage from the TFT sensor is less than 0.03 V when the following conditions are met. Time since engine start: more than 180 s Vehicle is driven for 90 s or more at vehicle speed between 25-59 km/h {15-36 mph}, and then 60 km/ h {37 mph} or more for 60 s or more Diagnostic support note The MIL illuminates if the TCM detects the above malfunction condition in two consecutive drive cycles or in one drive cycle while the DTC for the same malfunction has been stored in the TCM. The AT warning light does not illuminate. PENDING CODE is available. FREEZE FRAME DATA is available. The DTC is stored in the TCM memory.
POSSIBLE CAUSE	Coupler component connector or terminal malfunction TFT sensor malfunction TCM malfunction
Courtesy of MAZDA MOTORS CORP.

DTC P0711:00

TFT sensor circuit range/performance

DETECTION CONDITION

The TCM detects that input voltage from the TFT sensor is less than 0.03 V when the following conditions are met.
- Time since engine start: more than 180 s
- Vehicle is driven for 90 s or more at vehicle speed between 25-59 km/h {15-36 mph}, and then 60 km/ h {37 mph} or more for 60 s or more

Diagnostic support note

The MIL illuminates if the TCM detects the above malfunction condition in two consecutive drive cycles or in one drive cycle while the DTC for the same malfunction has been stored in the TCM.
The AT warning light does not illuminate.
PENDING CODE is available.
FREEZE FRAME DATA is available.
The DTC is stored in the TCM memory.

POSSIBLE CAUSE

Coupler component connector or terminal malfunction
TFT sensor malfunction
TCM malfunction

Courtesy of MAZDA MOTORS CORP.
